Notting Hill, London

Download case study

Download your own copy of this case study in PDF format.

Download

About this project

Full design and specification of discreet cooling and ventilation systems to a 5-bedroom, four-storey and basement stucco terraced townhouse in the heart of Notting Hill, for a luxury design-and-build firm and a renowned London architect.

  • Client

    Private client

  • Appointed by

    OLF Construction

  • Design

    Stephen Turvil Architects

Technology used in this project

Climate Control
Comfort Cooling
Mechanical Ventilation
MVHR System
Decentralised Extract
Centralised Extract
Ductwork & Accessories
Ductwork
Plenums
Volume Control
Fire Dampers
Access Panels
Diffusers & Grilles
Linear Diffusers
Joinery Slots
Noise Management
Acoustic Treatment
Duct Attenuation
Acoustic Enclosure
Controls & Monitors
Control System
Discreet linear bar grille along the top of kitchen joinery room framing for kitchen air conditioning Plaster-in linear bar grille in the wall in luxury property in Arundel Gardens Plaster-in linear bar grille in the wall in luxury property in Arundel Gardens Single slot diffuser for air conditioning in a lime plastered ceiling in a luxury residential property in Arundel Gardens, London Bespoke living room joinery concealing air conditioning equipment Discreet ceiling linear bar grille in the bar area, out of the main ceiling line for invisible air conditioning Discreet ceiling linear bar grille in the bar area, out of the main ceiling line for invisible air conditioning Discreet bathroom ventilation air terminals Bespoke air conditioning provision to bedroom in Kensington plaster-in linear bar grille Bespoke air conditioning provision to bedroom in Kensington plaster-in linear bar grille Plaster-in twin slot diffuser in residential bedroom for discreet air conditioning External acoustic enclosures for silent air conditioning concealed in the lightwell in a London conservation area

Design Brief

Full detailed design and equipment specification from concept stage derived from the requirements of the end client. Furnished in classic contemporary style with Scandinavian influences, the system design was directed by the visual intent of the property to deliver a solution as discreet and seamless as possible.

Solution

Using bespoke joinery in the ground floor kitchen to conceal fan coil units, a narrow-gauge linear bar grille running the length of the wall at the top of the joinery conditions the room and adds visual definition to the ceiling line.

The first-floor dining and lounge area is supplied by a horizontal unit in the adjoining powder room ceiling, through a minimal wall-length plaster-in diffuser. A fine-line plaster-in bar grille inside the bar alcove ceiling provides a path for return air, positioned outside of the main ceiling line to be beyond line of sight.

On the second floor, an identical grille supplies the master bedroom, with return air through a series of minimalist joinery slots. The requirement for comfort cooling to be almost inaudible in this room led to attenuation of the unit for almost completely silent system operation. Discreet plaster-in diffusers and joinery slots provide supply and return air paths to the three children’s bedrooms on the third floor, while climate control to the fourth-floor guest bedroom and wellness room takes place through a single linear diffuser in each ceiling, aligned with the bespoke coving detail.

A unique combination of centralised and decentralised ventilation from a single MVHR unit provides fresh air to the basement and bathrooms through a series of invisible shadow gap details.

Collaboration with the home automation contractor resulted in a design fully integrated with the Lutron system and controlled by a series of sleek black wall controllers and infrared remotes.

Two external condenser units housed in an acoustic enclosure under the lightwell stairs, flush with the wall, provides the supply air to the property in line with local planning requirements, invisible and inaudible from the road.
